Feature :
1. Supports all ISDB-T broadcast (1, 3, 13 segment), MPEG-2/MPEG-4 AVC/H.264 HD/SD Video , DiVX compliant
2. Compatible with 576i/576p/720p/1080i video formats
3. Auto and manually scan all available TV and radio channels
4. Aspect ratio 16:9 and 4:3, 1000 channels memory, parental control
5.HDMI, YPbPr, RCA, coaxial output
6. Teletext/ Bit Map subtitle, compliant with ETS1
7. Supported 7-Day EPG function, VBI Teletext
8. Support 6MHz software setting
9. Auto/Manual Program search, Multi-language supported
10. USB 2.0 for PVR, Software upgrade, Multimeida Playback
11. Demodulation: QPSK / 16QAM / 64QAM/QPSK or DQPSK;OFDM Reception Channel:: 7CH-68CH
12. Digital reception covers VHF & HUF band

Powerful Multimedia Features
Photo: JPEG,BMP,PNG
Audio: WMA、MP3、AAC (.wma、.mp3、m4a)
Video: MPEG1、MPEG2、MPEG4、H264、Motion JPEG  (.avi、.mpg、.dat、.vob、.div、.mov、.mkv、.mjpeg、.ts、.trp)
NTFS、FAT32、FAT16
Jpeg/Audio combo playback

ISDB-T Tuner(Toshiba)
Input frequency:13-62 Ch(470mHz~806mHz)
Input level:-90 ～ -5dBm
Bandwidth:6 MHz
Input impedance:50 Ω

Channel Decoding
Wave form: COFDM
Demodulation: QPSK,16QAM,64QAM, QPSK or DQPSK
FEC: 1/ 2, 2/3, 3/4, 5/6. 7/8 Automatic
Mode: 2K, 4K, 8K
Guard: 1/4, 1/8, 1/16, 1/32

Demultiplexer
Standard: ISO/IEC13818-1, MPEG-4HE AAC
Input Max. bit stream rate: 23.420Mbps

Video Decoding
Standard: ISO/IEC 13818-2, MPEG-2 MP@ML, H.264
Aspect ratio: 4:3, 16:9
Video format: PAL / NTSC/ AUTO
Video resolution: 1080p/1080i/720p/576p/576i(PAL),1080i/720p/480p/480i(NTSC)


Audio Decoding
Standard: ISO/IEC 13818-3
Decoding: MPEG-1 Layer I and II, MPEG-2, MPEG-4 AAC, MP3
Output mode: R/L, Coaxial, HDMI
Sampling frequency: 32, 44.1, 48KHz

Display: LED display
Processor and Memory
CPU: Mstar MSD7816
Frequency: 216 MHz
SDRAM:512MB
Flash Memory: 4MB

AV Output
Video de-emphasis: CCIR REC.405-1, 1080i/1080p
Video bandwidth: 5.5 MHz
Video output impedance:75 Ω
Video output level: 1.0Vp-p
Audio output: Coaxial, L/R, HDMI
Audio output frequency:20Hz ~ 20KHz
Audio output impedance:Low
Audio output level: A 1.0Vrms ± 2dB into 10K

Hardware Interface
Indicators: Power, signal lock
IR Receiver: 38KHz
AV output: YUV, HDMI, Composite Video
RF Input: EC-type IEC169-2 Female
Loop Through Out: IEC-type IEC169-24 Male
USB: USB1.1.1- USB2.0
Power input Spec.: 90—260V AC 8W max
* CE/RoHS/EUP 2010 compliance
